INSTALLATION INSTRUCTIONS
Remove Stem Top
1
Loosen the stem top and remove
it from the stem.
Stem Top
Stem
- 4 -
Install Bulb
2
Insert the bulb with correct wattage
and type marked on the xture label
and push rmly into place.
CAUTION: Do not exceed
maximum wattage marked on
luminaire label.
Socket
Bulb
Place the stem top over the
bulb and thread the stem top
onto the stem. Hand tighten
until snug.
Install Stem Top
3
Stem Top
Stem
VOLT
®
Path & Area Light Stem
VSM-2407 & VSM-1203
