VOLTCRAFT BS-15 User Manual

Main menu bar
File Set Capture File Selection of the memory location for video
recordings (avi). The ending “.avi” must be
indicated.
Allocate File Size Set the memory size The available size is
displayed.
Under the menu point “Capture File Size” the
size can
be entered.
Save Captured Video Saving of a recorded video sequence.
Exit Exit the program.
Options Preview Real-time display in the main window.
Capture Start Capture Start of a video recording. Conrm the
displayed stor-
agelocationwith“OK”.
Stop Capture Stops the recording.
Set Frame Rate Set frame rate for the recording (frames/
sec.)
Set Time Limit Input of a max. recording time in
seconds.
Under the main window, the amount of the recorded images is displayed in the status line.
The supplied driver is „TWAIN32 compatible“. Thus, the camera can be operated with
every program that supports this interface.
Snapshot
In order to save individual pictures, press the key “7” on the endoscope. Another window 1.
opens displaying the snapshot image.
Under the menu point “File” you can save the picture (Save) or discard and exit (Exit). 2.
Under the menu point “Rotate orientation” you can rotate the picture. 3.
The snapshot function can only be carried out with administrator rights. Contact your
system administrator for this.
Digital zoom
Press the “6” key to zoom in. The zoom can go up in four steps, then returns to the original zoom
level.
Accessories - Magnetic top, mirror top and hook top
To install an accessory, open it gently and mount it on the camera head. Do not bend
accessories excessively when opening. This could break the part.
Magnetic top
Themagnetictopcanbeusedtosearchforandndlostmetalparts.
Mirror top
Themirrortopcanextendthesightoftheendoscopeintosomeplaceswhicharedifcultto
access for the camera head.
Hook top
The hook top can help you grasp a tiny piece of object.
MAINTENANCE AND CLEANING 8.
The product requires no servicing on your part apart from occasional cleaning. Use a soft,
antistatic and lint free cloth for cleaning.
Rinse the gooseneck of the endoscope carefully with clean water after each application in liquids
and dry it before storing it in the case.
DISPOSAL9.
Electronic devices are recyclable waste and must not be disposed of in the household
waste.
At the end of its service life, dispose of the product according to the relevant statutory
regulations.
TECHNICAL DATA10.
Resolution: 640 x 480 Pixel (VGA)
Frame rate: 30 fps (frames/sec)
Picture: 24 Bit RGB Colour (1/6"CMOS)
White comparison: Automatic
Exposure to light: Automatic
Video format: AVI
Camera illumination: 2 LEDs, white
USB port: USB 1.1
Power Supply: 5V via USB
Ambient/ operating
temperature:
0 to +45°C
Cable length: approx. 200 cm
Total length of device: 115 cm
Effective length of endoscope: 96 cm
Minimum Bending radius: 6 cm
Diameter of camera head: 11.2 mm
Lens coverage: 54°
Focus: > 6 cm
Weight without accessories: approx. 415 g
Legal notice
These operating instructions are a publication by Voltcraft®, Lindenweg 15, D-92242 Hirschau/Germany, Phone +49 180/586 582 7
(www.voltcraft.de).
Allrightsincludingtranslationreserved.Reproductionbyanymethod,e.g.photocopy,microlming,orthecaptureinelectronicdataprocessing
systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2012 by Voltcraft®
