8. Display indications and symbols
This is a list of all possible symbols and statements on the DMM.
AUTO Automatic range selection is active
HOLD Data hold function is activated
OL Overload, the measuring range was exceeded
OFF Off position. The DMM is switched off.
Symbol for battery change
Symbol for the diode test
Symbol for the acoustic continuity tester
OFF Symbol for “button not pressed” (function off)
ON Symbol for “button pressed” (function on)
AC Alternatingsizeforvoltageandcurrent
DC Direct magnitude for voltage and current
mV Millivolt (exp.-3)
V Volt (unit of electric potential)
Ω Ohm (unit of electric resistance)
kΩ Kiloohm (exp.3)
MΩ Megaohm (exp.6)
MAX Maximum value display
9. Inserting/charging the batteries
The multimeter requires two AAA batteries for operation. You need to insert new, charged batteries prior to initial
operation or when the battery change symbol appears on the display.
The signal transmitter requires a )V compound battery just like the receiver. You need to change the battery when the
display “L2” is lit or if there is no audible sound on the receiver.
1To insert/replace the batteries in the DMM, proceed as follows:
• Disconnect the measuring device from all measuring circuits and turn it off.
• Remove the protective rubber frame (12) from the device.
• Undo the screws on the battery compartment cover (11) and remove the cover.
• Place new batteries into the battery compartment observing the correct polarity.
• Now close the housing carefully again.
