VOLTCRAFT LSG-4 - Technical Specifications

40
Operating conditions .........................................0 to 40°C (<75%rh)
Storage conditions ............................................-10 to +50°C (<80% RH)
Dimensions (L x W x H) .................................... 162 x 74 x 44 mm (DMM)
233 x 56 x 27 mm (Receiver)
Weight .............................................................. ca. 308 g (DMM)
ca. 125 g (Receiver)
1Cable detector
Signal ................................................................permanentsoundca.800–860Hz
wobblesoundca.800–1050Hz
Status indicator .................................................max. 50 V
Continuity tester ................................................<10kΩ(optical)
Measuring cable length .................................... banana clips approx. 50 cm each
modular plug ca. 25 cm
Overload protection ..........................................<75 V/DC, <50 V/AC
2Measuring tolerances
Statement of accuracy in ± (% of reading + display error in counts (= number of smallest points)). The accuracy is
valid for one year at a temperature of +23°C ± 5°C, and at a relative humidity of less than 75%, non-condensing.
3V/DC
Range Resolution Accuracy
200 mV 0.1 mV ±(0.8 % + 4)
2 V 0.001 V
±(1.3 % + 4)
20 V 0.01 V
200 V 0.1 V
600 V 1 V
Overloadprotection:600V;impedance>7.5MΩ
4Alternating voltage V/AC
Range Resolution Accuracy
2 V 0.001 V
±(1.3 % + 6)
20 V 0.01 V
200 V 0.1 V
±(1.8 + 10)
600 V 1 V
Frequencyrange50–60Hz;averagevaluewithsinusvoltage;overloadprotection600V;impedance>7.5MΩ
