V-ONE USER MANUAL
8
V-One Technical Specications
Disclaimer: Voltera reserves the right to change or update the following specications at
any time without notice. Please visit voltera.io/store or contact support@voltera.io for the
most up-to-date information.
Hardware
Software
Printer Properties
Maximum Dimensions 40 x 26 x 21 cm 16 x 11 x 9 in
Weight 7 kg 16 Ibs
Environmental Conditions
Operating Temperature 15 – 30º C 59 – 86ºF
Maximum Altitude 2000 m 1,24 miles
Relative Humidity 80%
Pollution Degree 2
Maximum Temperature 240ºC 464ºF
Ramp Rate 2º C/s 3,6ºF/s
Power Requirements
Voltage 100 – 120 ACC 200 – 240 ACC
Current 4,7 A 50/60 HZ 2,5 A 50/60 HZ
Power 575W
System Requirements Windows 7 and up(64 bit) Mac OSX 10,11 and up
Input File Type Gerber
Connection Type Wired USB
Technology Direct-Write Dispensing
Magnetically Interchangeable Print Head
Height Control Active Height Mapping With Detachable Probe
20 um Repeatability
Print Area 13,5 x 11,4 cm 5,3 x 4,4 in
XYZ Resolution 10 ; 10 ; 0,625 um respectively
Feature Size
Minimum Line Dimensions* 0,2mm Space/Trace 8 mil Space/Trace
Minimum Dot Diameter* 0,5 mm 0,019 in
*With standard 9mil (inside diameter) nozzle
V-ONE USER MANUAL
9
Consumables & Accessories
The items below are compatible
consumables. Please visit
voltera.io/store to view or purchase
additional consumables.
The items below are the compatible
accessories. In the case of damaged or
lost accessories, please contact
support@voltera.io for replacements.
• 2 ml Conductive Ink Cartridge
• 2 ml Solder Paste Cartridge
• 3 g Flux
• 10 g SniAg1 Solder Wire
• Precision Dispensing Nozzles - Pack of 4
• Burnishing Pad – Pack of 4
• 3” x 4” Substrate – Pack of 6
• 2” x 3” Substrate – Pack of 10
• 4” x 5” Substrate – Pack of 6
• Windows 7 and up (64-bit only) –
Visit support.voltera.io/desktop-application to
download the drivers. Remember to install the
drivers with administrator privileges.
• Probe Assembly
• Dispenser Assembly
• Substrate Clamps
• Thumbscrews
• Mac OSX 10.11 and up –
Apple’s native drivers work with the V-One
out of the box. There is no need to install
a separate driver.
Install the Software
Drivers: Before you install the V-One software it is important to install the printer drivers.
Most connection issues experienced are because the wrong drivers are being used.
Unbox And Choose a Location For Your V-One
Application: Visit support.voltera.io/desktop-application to download the desktop
application.
Setting Up Your V-One
1. Place the V-One on a at, level, and non-ammable surface. Be sure to position the V-One so that
the power inlet is easily accessible.
2. A well ventilated area is recommended.
3. Remove all items from the box. Place the ink and solder paste in the fridge for storage.
4. Make sure you keep all packaging in case the product needs to be transported in the future.
5. Check the voltage rating on the back of the unit to make sure it matches the power provided in the
country of use.
6. Connect the provided power cable to the C14 receptacle at the back of the V-One, then to an
earthed socket outlet.
7. Connect the provided USB cable to the V-One, then to your computer.
