VOLTIMA SCD 12 - Instructions for Battery Charging

Instructions for Battery Charging
(Please consult the connection plan for your device!)
Setting the Battery Charging Program
For battery MAIN I, set the correct charging program for the battery type
(lead or lithium-iron phosphate technology).
Prior to start-up, set the correct characteristic line of charging suitable for
the battery to avoid damage to the battery! Only use lithium iron-phosphate
batteries in execution with integrated BMS (battery management system)
and safety circuit!
Set the DIP switches on the side of your device to the correct battery type
in accordance with the following tables:
SCD 12 , SCD 25
1
2
3
4
GEL
↓
↑
↓
↓
Wet
↓
↓
↑
↓
AGM
↓
↓
↓
↑
LiFePO4
↑
↓
↑
↑
SCN 20 , SCN 40
1
2
GEL
↓
↓
Wet
↑
↓
AGM
↓
↑
LiFePO4
↑
↑
Charging Parameters
* The se values apply to 12V or 24V systems
Battery
Voltage
Voltage
Standard
(Boost Charging)
(Float Charging)
Temperature
Type
SCD12
SCN20
SCD12
SCN20
SCD12
SCN20
SCD25
SCN40
SCD25
SCN40
SCD25
SCN40
GEL
14,3 V
14,3 V /
13,8 V
13,8 V /
20 °C
25 °C
(3-10 h)
28,6 V *
27,6 V
*
Wet
14,4 V
14,7 V /
13,45 V
13,5 V /
20 °C
25 °C
(1,5-6 h)
29,4 V *
27V*
AGM
14,7 V
14,4 V /
13,5 V
13,5 V /
20 °C
25 °C
(1,5-5 h)
28,8 V *
27V*
LiFePO4
14,6 V
14,6 V /
13,6 V
13,6 V /
20 °C
25 °C
(0,5-3 h)
29,2 V *
27,2 V
*
