76
209. Install the frame arrester cover. Tool width: 10
mm.
210. Connect the hose from the oil trap to the under-
side of the flame arrester.
211. Install the exhaust manifold with a new gasket.
Tool width: 1/2" or 13 mm.
NOTE! The gasket will only fit one way. The 2 short
bolts to be installed up front.
212. Install the pipe between the oil cooler and the
exhaust manifold. Tool width: 10 mm. Check the
sealings. Replace if necessary.
213. Put new sealings on the cooling water pipes
and a new O-ring on the heat exchanger and install
the heat exchanger to the pipes. Assemble the heat
exchanger to the thermostat housing. Tool width: 12
mm.
214. Install the heat exchanger on the exhaust mani-
fold. Tool width: 12 mm.
