Presentation
Engine 3.0GS
1. Starter Motor
2. Oil Withdrawal Tube
3. Oil Filter
4. Fuel Pump
5. Oil Level Dipstick
6. Circuit Breakers
7. Type Plate (engine).
See page 12
8. Water-Cooled
Exhaust Pipe
9. Type Plate (shield).
See page 12
10. Seawater Pump
Please note! The photos below do not show all engine/transmission combinations. If your engine does not have
the drive shown, refer to another engine with the relevant drive for an introduction to the transmission.
11. Fuel Filter
12. Cover for flame arrestor
and carburetor
13. Generator (GEN)
14. Cover for flame arrestor
and throttle housing and
electronic controls
15. Power Steering Pump
22
19
20
9
813
16
21
15
23
17
SX-C, SX-M Drive
16. Draining Oil
17. Seawater Intake
18. Sacrificial Anodes
19. Oil Level Dipstick
20. Topping Up Oil
21. Trim Cylinder
22. Type Plate
23. Sacrificial Anode,
SX-C
