2 0 0 4
VOLVO
V70
Chapter 3 - Climate control system
pg. 45 Climate control system
Ventilation 46
Climate control system - general information 47
Electronic Climate Control (ECC) 48
Manual climate control with air conditioning, A/C 52
pg. 46 Ventilation
Air vents in dash
Air vents (dash)
A Open
B Closed
C Horizontal air flow
D Vertical air flow
Direct the outer air vents toward the side windows to demist.
In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows.
