Service Information
Document Title: Function Group: Information Type: Date:
Lifting machine 050 Service Information 2014/8/27
Profile:
ART, A35E, A35E FS, A40E, A40E FS [GB]
Lifting machine
Op nbr 09001-1
WARNING
Never stand under the machine when it is suspended in the air.
WARNING
The lifting tool may only be installed with the special nuts supplied with the tool.
The lifting tool is considered to be equipment
NOTE!
The lifting tool must only be installed on the machine when lifting and transporting it.
NOTE!
It is important that the correct tools and special nuts are used and that the lifting tool is fitted correctly.
Lifting tool Nut
Part no. 15011655 Part no. 11193630
1. Park the machine on a level surface.
2. The machine must be switched off and the main current disconnected.
3. Lock the steering joint with the steering joint lock.
Figure 1
