09 Maintenance and service
Replacing bulbs
09
* Option/accessory, for more information, see Introduction.
239
Passenger compartment lighting in
cargo area
G010326
Cargo area lighting also includes a further lamp
on the left-hand side of the cargo area.
1. Insert a screwdriver and gently turn so that
the lens detaches.
2. Unplug the connector from the bulb holder.
Vanity mirror lighting*
G020253
Removing the mirror glass
1. Insert a screwdriver underneath the lower
edge, in the centre. Carefully prize up the
lug on the edge.
2. Insert the screwdriver underneath the edge
on the left and right-hand sides (by the
black rubber sections), and prize carefully
so that the glass comes loose in the lower
edge.
3. Carefully detach and lift aside the entire
mirror glass and cover.
4. Remove the blown bulb and replace it with
a new one.
Fitting the mirror glass
1. First, press the three lugs at top edge of
mirror glass back into position.
2. Then press the three lower lugs back into
position.
