09 Maintenance and service
Fuses
09
* Option/accessory, for more information, see Introduction.
247
60. Seat heating (driver's
side)
15 A
61. Seat heating (passenger
side)
15 A
62. Sunroof* 20 A
63. Reserve –
64. Reserve –
65. Audio, Infotainment 5 A
66. Audio, Infotainment, Cli-
mate control system
10 A
67. Reserve –
68. Cruise control 5 A
69. Climate control system,
Rain sensor, Buttons for
BLIS*, parking assis-
tance*, DRIVe
5 A
70. Reserve –
71. Reserve –
72. Reserve –
73. Sunroof*, Overhead con-
sole for interior lighting,
Seatbelt reminder, rear,
Dimming, interior rear-
view mirror*
5 A
74. Fuel pump 15 A
75. Reserve –
76. Reserve –
77. Reserve –
78. Reserve –
79. Reversing lamp, Dim-
ming, interior rearview
mirror (signal)
5 A
80. Reserve -
81. Reserve –
82. Supply to front right door 25 A
83. Supply to front left door 25 A
84. Power seat, passenger 25 A
85. Power seat, driver 25 A
86. Interior lighting, cargo
area lighting, power
seats, fuel level display
(2.0F)
5 A
