M
e
c
h
a
n
i
c
a
l
s
u
s
p
e
n
s
i
o
n
s
e
a
t
1
H
e
a
d
r
e
s
t
a
d
j
u
s
t
m
e
n
t
The headrest can be adjusted for height by pulling
up or down. End stops limit the movement. It can be
also adjusted for angle by pushing forwards or
backwards. End stops limit the movement.
2
B
a
c
k
r
e
s
t
a
n
g
l
e
a
d
j
u
s
t
m
e
n
t
Lift the lever (2) and press the backrest rearward to
required position.
3
H
o
r
i
z
o
n
t
a
l
a
d
j
u
s
t
m
e
n
t
,
t
o
p
s
e
a
t
Lift the lever (3) and push the seat forward or
rearward.
4
H
o
r
i
z
o
n
t
a
l
a
d
j
u
s
t
m
e
n
t
,
t
o
p
s
e
a
t
a
n
d
c
o
n
s
o
l
e
s
The seat and the consoles can be adjusted
forwards and backwards. Lift the lever (4) and move
the seat and consoles to the desired position.
N
O
T
E
!
The operator seat is adjusted in a correct way in
order to obtain the best possible comfort.
5
S
u
s
p
e
n
s
i
o
n
a
d
j
u
s
t
m
e
n
t
Adjust the seat to the drivers weight by turning the
weight adjusting handle (5).
N
O
T
E
!
Never adjust the height of the seat with the
suspension adjusting handle (5).
6
S
e
a
t
a
n
g
l
e
a
d
j
u
s
t
m
e
n
t
Lift the lever (6) to adjust the seat angle.
7
A
r
m
r
e
s
t
a
d
j
u
s
t
m
e
n
t
Inclination of the armrest can be changed by turning
the adjustment knob (7) mounted on the underside
of the armrest. The armrests can be manually
tipped up if required.
1 Headrest adjustment
2 Backrest angle adjustment
3 Horizontal adjustment, top seat
4 Horizontal adjustment, top seat and
consoles
5 Suspension adjustment
6 Seat angle adjustment
7 Armrest adjustment
