Only for machines with blade:
The cover on top of the blade must be taken away before towing to avoid scratches. Lift the cover up, take the
cotter pin (B) and arrange the cover bracket that the cotter pin goes through the hole (A) in the cover bracket and
the blade frame. Now as the cover bracket is in a fixed position, open the four screws (B) on top and remove the
cover.
A
V1106739
Fixation of cover bracket on machines with blade
B
V 1106740
Removing of cover on machines with blade
N
O
O
T
T
E
E!
Take care that the towing device is not scratching over any sharp
edges, use a protection if needed.
To avoid oblique loading, pull the machine straight rearwards or
forwards. Keep the towline angle as small as possible, maximum
angle is 10°.
Ma
x
xi
m
mu
m
m t
e
empora
r
ry f
o
o
r
rce on t
h
h
e
e t
o
owi
n
ng eyes must n
o
o
t
t exce
e
e
d
d t
h
h
e
e f
o
ol
l
low
i
ing
:
:
V1161529
LC=xxxx daN
F
RES
Direction EW160E EW180E
F
Res
/ LC (daN) 10350 daN 11050 daN
Maximum towing angle 10 ° 10 °
1000kg = 9810N = 981daN = 9,81kN
Load per device _ 2 devices are required for towing
