Volvo EW180E - Page 286

L
Lubrication points(number of nipples in brackets)
1 A Pivot pin bearing (2) front and rear side
1 B Pivot pin bearing (1) front side, only machine without dozer blade / outrigger in front
2 King pin bearing (2+2)
3 Stabilisers plate (2)
4 Stabilisers cylinder bearing (4) (two nipples only accessible with lowered stabilizer legs)
5 Stabilisers pins (2)
6 Dozer blade bearing left (4) and right (4)
7 Dozer blade cylinder bearing (4)
