09 Maintenance and service
Fuses
09
242
Relay/fuse box in the engine compartment
G007446
The fuse box has 36 fuse positions. Be sure to
replace a blown fuse with a new fuse of the
same colour and amperage.
•
Fuses 19-36 are of the "Mini Fuse" type.
•
Fuses 7-18 are of the "JCASE" type and
should be replaced by a workshop.
1
•
Fuses 1-6 are of the "Midi Fuse" type and
must only be replaced by a workshop.
1
On the inside of the cover there are tweezers
that facilitate the procedure for the removal
and fitting of fuses.
1
An authorised Volvo workshop is recommended.
