02 Instruments and controls
Windows, rearview and door mirrors
02
78
4. Press the button (1) repeatedly until the
number for the required magnetic zone (
1–
15
) is shown, refer to the map of magnetic
zones for the compass.
5. Wait until the display returns to showing
the character
C.
6. Following which, press and hold the button
in for 9 seconds and select
L for left-hand
drive cars and
R for right-hand drive.
7. Drive slowly in a circle with a maximum
speed of 10 km/h until a compass direction
is shown on the display, which indicates
that the calibration is complete.
G020150
Magnetic zones, Europe.
G020151
Magnetic zones, Asia.
G020152
Magnetic zones, South America.
G020153
Magnetic zones, Australia.
G020154
Magnetic zones, Africa.
