To remove the steel grid, perform the above steps in the reverse order.
Green mark - locked position.
Red mark - unlocked position.
Cargo net (option on V70)
Models with 2-section rear seat
Your car can be equipped with a cargo net made of strong nylon fabric that can be unrolled from the rear
seat backrest. After being unrolled, the cargo net self-locks after about a minute.
● Pull up the right-hand cargo net.
● First hook the rod in the bracket on the right-hand side (A). Then pull the rod out and hook it on the
left-hand side (B).
● Pull up the left-hand cargo net and secure it to the rod.
● To remove, proceed in reverse order.
NOTE: Make sure that the cargo net is securely fastened in the hooks. To remove, proceed in reverse
order.
The cargo net can also be used when the rear seat is folded forward.
pg. 64 Nylon cargo net (V70 XC with 3-section rear seat)
