Volvo V70R User Manual

177
Maintenance and service
Replacing bulbs
Dipped beam bulb
Dipped beam
To remove the bulb:
– Switch off all lights and turn the ignition
key to position 0.
– Remove the cover.
– Unplug the connector.
– Disconnect the spring clamp. First push
to the right so that the spring disconnects
and then out and down.
– Pull out and remove the bulb.
Fitting the dipped beam bulb
To fit:
– Fit the new bulb. In can only be
positioned one way.
– Press the clamp spring upwards and a
little to the left so that it secures in its
catch.
– Plug in the connector.
– Refit the cover.
Main beam bulb
Main beam
To remove the bulb:
– Switch off all lights and turn the ignition
key to position 0.
– Remove the cover.
– Pull out the lamp.
– Unplug the connector.
– Turn the lamp anticlockwise a half turn,
pull out and remove the bulb.
