Vonets VAP11G-300 User Manual

VONETS
7
6) After rebooting the device, the device will automatically connect to the configured
WiFi hot spot, if it is configured successfully, the green indicator will flash quickly.
Note 1: When bridge/repeater product connect to external network, the IP address of the device
will change. At this time, when log in configured page, we suggest you enter configured
domain name: http://vonets.cfg. Or in Windows command window, enter the command:
ping vonets.cfg, to get the IP address of the device, then log in configuration page with
this IP.

Vonets VAP11G-300 Specifications

General

Wi-Fi Standard	802.11b/g/n
Frequency	2.4GHz
Max Data Rate	300Mbps
Weight	30g
Storage Temperature	-20°C to 70°C
Antenna	Built-in
Operating Mode	AP, Repeater
Ethernet Port	10/100Mbps
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Port	RJ45
