Voptech VI2006 and Elastix Server Setup Guide
2
1.0 Setup Diagram
Figure 1-1 is a setup diagram for a single IP Phone Voptech VI2006 configuration. The
phone is setup as a SIP telephony device.
Figure 1-1. Setup Diagram
2.0 Host PC Environment
Table 2-1. Host Server Environment Details
Description
Hardware Type
Elastix Appliance ELX-Series
Hardware Version
ELX-3000
Software Type
Elastix
Software Version
2.3
3.0 Test Setup Equipment
Table 3-1. Test Setup Equipment
Equipment
Model
Version
IP (SIP) Phone
N/A
N/A
Voptech IP Phone
VI2006
1.7.130.93
Switch
N/A
N/A
