STEP 4: Prepare Dry Side
•
Determine the glass thickness by measuring it or
contacting the aquarium manufacturer, and then
choose the appropriate thickness spacer.
• Remove all stickers and waxpaper from the motor
assembly, revealing the adhesive (Figure C).
• Hold the dry side with the power cord pointing up,
and align the hook on the thickness spacer with
the power cord. Firmly press the thickness spacer
against the dry side to attach them (Figure D).
5
STEP 5: Place Dry Side on Aquarium
•
Hook the thickness spacer to the hanger (Figure E).
• Tie cord to mounting tab using a zip tie (Figure F).
Trim the exces end of the zip tie.
Never place the dry side in the aquarium.
Failure to use the rubber spacer can damage the
pump, which will NOT be covered under warranty.
