Radian
™
TRIPOD BALL HEAD
6 7
Attaching Optics to Ball Head
The Radian
™
Ball Head uses Arca-Swiss style quick-release plates. To mount your optic to
the tripod:
1. Twist the Quick-Release Locking Knob counter-clockwise to remove the Quick-Release Plate.
2. Attach the plate to your optic. Be sure to tighten the Mount Bolt from the bottom side of the
plate and flip the D-ring so it lies flat.
3. Place the Quick-Release Plate back into the tripod head and turn the Quick-Release Locking
Knob clockwise to securely lock the plate in the head.
NOTE: To mount binoculars to the tripod, a binocular
adapter is required. Purchase Vortex
®
binocular adapters
from your local dealers.
NOTE: Some optics are designed to be Arca-Swiss
compatible and can be mounted to the tripod head
without the need for plates.
TIP: Purchase additional quick-release plates for your
optics so it is easy for you to switch equipment.
Quick-Release Plate
and Mount Bolt
Quick-
Release
Locking
Knob
VIP WARRANTY
OUR UNCONDITIONAL PROMISE TO YOU.
We promise to repair or replace the product. Absolutely free.
Unlimited
Unconditional
Lifetime Warranty
service@VortexOptics.com • 800-426-0048
Note: The VIP Warranty does not cover loss,
theft, deliberate damage, or cosmetic damage
not affecting product performance.
For additional information, and the most up-to-date
product manuals, visit VortexOptics.com
