Chainsaw VO2811
9
Risk of injury during operation!
Improperly mounted parts can cause
severe and even fatal injuries when
using the device! This device may
only be commissioned if all parts are
mounted completely and tightly and
no part is damaged!
•
Therefore, read the whole chap-
ter before you assemble the
parts!
•
Assemble the parts carefully and
completely.
•
Use tools when their use is sug-
gested.
Risk of injury during assembly!
Parts may only be assembled and
disassembled when the motor is
switched off (de-energise device).
If one of the parts should be missing
or damaged, please contact the
vender.
Risk of injuries due to cuts!
The teeth of the saw chain are very
sharp! Protective gloves must be
worn for all work on the chain.
Breathing in of particles from cut items
•
Contact with petrol/oil
For this reason, it is essential that this chain
saw is always used with the additional per-
sonal protective equipment as shown on the
machine and described in these operating
instructions. It is also necessary to observer
the safety notes.
Your device at a glance
► P.2 , item 1
1. Handle
2. Saw chain
3. Chain bar
4. Chain Adjustment Ring
5. Fastening Bolt for Chain Sprocket
Chain Wheel Cover
6. Sight glass for oil level
7. Rear hand guard
8. Hand guard
9. Handle
10. Fill opening for chain oil (tank cover)
11. Switch-on safety lock
12.
Start button
13. Strain relief mechanism for extension
cable
14. Chain Wheel Cover
15. Tension Plate
16. Bar bolt
17. Sprocket
Scope of delivery
•
Drive unit
•
Saw bar
•
Saw chain
•
Protective cover
•
Instructions for use
Assembling the saw bar and saw chain
–
Lay the saw on flat surface.
–
Turn the fastening bolt (5) anti-
clockwise and loose the chain
adjustment ring（4）to remove the
sprocket chain wheel cover（14）.
–
To fit the new bar, place the bar (3) onto
the bar bolt (16) with the tensioning
plate (15) pointing outwards.
Risk of injury!
An improperly mounted saw chain
causes uncontrolled cutting behav-
iour of the device! When assembling
the chain, heed the prescribed run-
ning direction!
Checking the chain greasing
NOTICE!
Device damage!
The device may not be used without
sufficient chain greasing. Insufficient
greasing reduces the service life of
the device.
Note:
When attaching the chain, heed the
correct position of the guide groove
(saw rail).
–
Spread the chain (2) out into a loop with
cutting edges running clockwise. Relax
the tensioning plate (15) against the
clockwise direction.
–
Slide the saw chain (2) into the bar
guide groove. To mount the Chain bar
(3),raise it to an angle of approx..45
degrees. This will make it easier to
replace the saw chain (2) onto the
sprocket (17). It is normal that the saw
chain (2) is slack. Sagging in the chain
is normal. .
–
Pre-tighten the chain (2) by turning the
tensioning plate (15) clockwise.
–
Position the sprocket chain wheel
cover (14). Only lightly tighten the
fastening bolt (5) , as you will still have
to tension the saw.
Tensioning the saw chain
► P. 3 , item 3
–
To tighten the chain, turn the chain
adjustment ring (4) clockwise. To loosen
the tension, the chain adjustment ring
(4) anti-clockwise.
–
Tighten the fastening bolt (5) again.
Letting the saw chain run in
During the run-in time, re-tension the saw
chain and rail after a maximum of 5 cuts.
Checking the tensioning of the saw chain
WARNING!
Risk of injury!
A new saw chain must be re-ten-
sioned after a maximum of five cuts.
This is normal during the run-in time;
the intervals between subsequent re-
tensionings will get larger.
The saw chain is tensioned correctly if it lies
close against the underside of the saw rail
and can be moved easily by hand.
Readjust tension of the saw chain when nec-
essary (► Re-tensioning the saw chain –
p. 14).
If there is sufficient chain greasing, the oil
spraying off of the saw chain will form a slight
trail.
–
Check the oil quantity in the tank.
–
Start the device.
–
Hold the running saw chain approx. 15 cm over a
suitable surface for a time (15 s).
Filling up saw chain oil
► P.3 , item 6
NOTICE!
Environmental damage!
Since the saw chain oil can penetrate
the environment during operation,
biologically-degradable special veg-
etable-based saw chain oils should
be used.
–
Lay device securely with the tank
cover (10) upwards.
–
Before opening, clean the tank cover and
the filler neck if necessary.
–
Slowly open and remove the tank cover.
–
Carefully fill up the saw chain oil. Do not
spill!
–
Read the oil level at the inspection
glass (6). .
–
Tighten the tank cover by hand.
–
If you have spilled any saw chain oil, be
sure to wipe it up.
Operation
Safety equipment
The device has several pieces of
safety equipment which reduce the risk
of injury when working:
