- 3 -
Operating State Solar Controller (Sun Symbol):
Depending on the solar controller, the operating state of the solar controller is indicated by the sun symbol.
− No sun: Solar power is not at disposal; the solar controller is in stand-by mode.
− Full sun: Solar power is at disposal, maximum possible charge
− Flashing sun: The controller limits the current because of a full or almost full battery to avoid battery
overcharging. For determination of the possible solar power, the battery must be discharged by a consumer (such
as lighting) until the solar controller supplies full power, and the sun symbol stops flashing.
General Information
Cleaning:
We recommend to use a damp microfibre cloth with pure water or, if required, with water with a few soap.
Take care that no liquid flows along the display screen or the edges of the front panel!
Never use solvents, aggressive household cleaners, and scratching or abrasive agents or objects to clean the
front panel and particularly the display itself.
Trouble-Shooting:
No display at all:
a) Reverse battery, fuse released Check!
b) Battery is totally discharged, below 7 volts Recharge immediately!
c) Connection cable is interrupted, damaged, or it is not inserted: Check!
"Hieroglyphs" on the display:
a) The internal check programs of the unit have found an (memory) error:
Withdraw the cable connector for 10 seconds. After that, an initial start-up is to be executed as described above.
Technical Data:
System:
Nominal Voltage 12 V and 24 V
Operating Voltage Range 8...32 V (of Solar Controller)
Current Consumption 3...30 mA, depending on illumination
Display Unit (LCD Display):
Technology LC Display with specific segments
Representation Surface 49 x 28 mm
Illumination white LED
Dimensions 80 x 85 x 24 mm
Assembly Dimensions approx. 66 x 72 mm
Weight approx. 55 g
Declaration of Conformity:
In accordance with the provisions of the statutory requirements and the relevant directives, Electrical
Equipment (Safety) Regulations 2016, Electromagnetic Compatibility Regulations 2016, The Restriction of
the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 this
product complies with the following standards or normative documents:
BS EN55014-1; BS EN61000-6-1; BS EN61000-4-2; BS EN61000-4-3; BS EN61000-4-4; BS EN62368-1;
BS EN50498, BS EN IEC 63000.
