- 12 -
Capacity Solar Module (recommended min. to max.): 40 - 170 Wp 50 - 260 Wp 50 - 360 Wp 50 - 440 Wp
Current Solar Module, 0 to maximum:
0 - 10 A 0 - 15.0 A 0 - 21.0 A 0 - 26.0 A
Voltage Solar Module, max. Open Circuit Voltage (Voc):
max. 60 V max. 60 V max. 60 V max. 60 V
Protection against Back Discharge (Night Operation): Yes Yes Yes Yes
Main Port Main/Leisure Battery (12 V):
Charging/Floating/Load Current:
0 - 13 A 0 - 18.5 A 0 - 26 A 0 - 32 A
Max. Prelim. Charg. Current (Totally Discharged Battery):
6.5 A (<10 V) 9.7 A (<10 V) 13 A (<10 V) 16 A (<10 V)
Nominal Voltage Battery Lead-Acid, Gel, AGM: 12 V 12 V 12 V 12 V
Recom. min. Battery Capacity (max. acc. to application):
> 40 Ah > 60 Ah > 80 Ah > 100 Ah
Nominal Voltage Battery LiFePO4: 12.0 - 13.3 V 12.0 - 13.3 V 12.0 - 13.3 V 12.0 - 13.3 V
Recom. min. Battery Capacity (max. acc. to application):
> 30 Ah > 45 Ah > 70 Ah > 90 Ah
Charging Programs for Gel/AGM/Acid/LiFePO4 Batteries: 8 8 8 8
Charging Voltage Limitation (max.):
15.0 V 15.0 V 15.0 V 15.0 V
Installed, Limitation of Charging Current /Overload Protection:
Yes / Yes Yes / Yes Yes / Yes Yes / Yes
Installed, Overtemperature/Short-circuit Protection:
Yes / Yes Yes / Yes Yes / Yes Yes / Yes
Installed, Cooling Fan with Temp. Control:
-- Yes Yes Yes
Current Consumption Stand-by
4 mA 4 mA 4 mA 4 mA
Unit Fuse (Type FKS):
15 A 20 A 30 A 40 A
Input for Battery I Temperature Sensor:
Yes Yes Yes Yes
Plug-and-go Connect. For Displays, such as LCD Solar Comput. S: Yes Yes Yes Yes
Signal Output for "EBL" Display "Solar Charging Current": Yes Yes Yes Yes
Control Output "AES" Refrigerator, max. Rating: -- 12 V / 0.2 A 12 V / 0.2 A 12 V / 0.2 A
Auxiliary Port Vehicle Starter (Lead) Battery (Start):
Nominal Voltage/Charging Current:
12V / 0 - 1.0 A 12V / 0 - 1.0 A 12V / 0 - 1.0 A 12V / 0 - 1.0 A
Installed, Limitation of Charging Current / Overload Protection:
Yes / Yes Yes / Yes Yes / Yes Yes / Yes
Installed, Overtemperature / Short-circuit Protection:
Yes / Yes Yes / Yes Yes / Yes Yes / Yes
Dimensions, incl. Mounting Flanges (mm): 131 x 77 x 40 131 x 77 x 40 131 x 77 x 40 131 x 77 x 40
Weight:
225 g 235 g 285 g 285 g
Ambient Temperature Range, Humidity of Air:
-20 to +45°C, max. 95 % r. H., no condensation
Declaration of Conformity:
In accordance with the provisions of Directives 2014/35/EU, 2014/30/EU, 2009/19/EC, this
product complies with the following standards or normative documents:
EN55014-1; EN55022 B; EN61000-6-1; EN61000-4-2; EN61000-4-3; EN61000-4-4;
EN62368-1; EN50498.
The product
must not be
disposed of in
the household
waste.
The product is RoHS compliant.
It complies with the directive
2015/863/EU for Reduction of
Hazardous Substances in electrical
and electronic equipment.
Recycling:
At the end of its useful life, you can send us this device for professional disposal:
You can find more information about this on our website at www.votronic.de/recycling
Delivery Scope: Available Accessories:
• MPP Solar Controller
• Operating Manual
- Temperature Sensor 825
- LCD Solar Computer S
- Cable set for connection of the solar controller
to EBL
Order No. 2001
Order No. 1250
Order No. 2007
Subject to misprints, errors and technical modification without notice.
All rights reserved. This material may not be published, broadcast, rewritten or redistributed in whole or part without the
express written consent of the manufacturer. Copyright VOTRONIC 02/2023.
Made in Germany by VOTRONIC Elektronik-Systeme GmbH, Johann-Friedrich-Diehm-Str. 2, 36341 Lauterbach/GERMANY
Phone: +49 (0)6641/91173-0 Fax: +49 (0)6641/91173-10 E-Mail: info@votronic.de Internet: www.votronic.de
