• Switch Unit 40
• Operating Manual
Technical Data:
Nominal Operating Voltage (DC): 12 V / 24 V
Operating Voltage Range (DC): 8.5 V – 32 V
Current Consumption ON 2 mA; 0.002 A
Current Consumption OFF
during of with control input: 0 mA
Switching current (load current) max.: 40 A permanent, 60 A 1 sec.
Undervoltage disconnection
Switch-off point: 8.5 V
Power-off Delay: 1 sec.
Cut-in Point (automatic return): 10.0 V
Power-up Delay: 2 sec.
Fitting Position of Unit any
Working Temperature Range: -20/+50 °C
Protection Class: IP21
Dimensions (mm): 90 x 60 x 38 mm
Weight:
97 g
Ambient conditions, humidity of air: max. 95 % RH, no condensation
Declaration of Conformity:
In accordance with the provisions of Directives 2014/35/EU, 2014/30/EU, 2009/19/EC, this
product complies with the following standards or normative documents:
EN55014-1; EN55022 B; EN61000-6-1; EN61000-4-2; EN61000-4-3; EN61000-4-4;
EN62368-1; EN50498.
The product
must not be
disposed of in
the household
waste.
The product is RoHS compliant.
It complies with the directive
2011/65/EU for Reduction of
Hazardous Substances in electrical
and electronic equipment.
Subject to misprints, errors and technical modification without notice.
All rights reserved, particularly the right of reproduction. Copyright VOTRONIC 07/18.
Made in Germany by VOTRONIC Electronic-Systeme GmbH & Co. KG, Johann-Friedrich-Diehm-Str. 10, 36341 LAUTERBACH/GERMANY
Phone: +49 (0)6641 / 91173-0 Fax: +49 (0)6641 / 91173-20 E-mail: info@votronic.de Internet: www.votronic.de
