Vox AC30CC2 Service Manual

THE ASSEMBLY PARTS LIST AC30CC1
P/N PART NAME DESCRIPTION QUA
550078-0300000000 REVERB BL3EB3CIB 1
550084-2261100090 AUDIO CABLE φ3.8MM L=1100MM 1
550217-1327000001 LOGO PLATE KIMANSON SUPPLIED 1
550226-0250041311 RUBBER FOOT 1 φ25x12.5 4
550300-2003000011 FRONT PANEL for CC1 Black Vin
y
l / Grill Cloth/White Pi
p
in
g
1
550301-2003000011 BACKBOARD 1 for CC1 Black Vinyl 1
550301-2003000021 BACKBOARD 2 for CC1 Black Vinyl 1
550306-2321000001 VENT ABS LXW=143x41 3
550308-2003000011 BOTTOM BOARD 1 for CC1 AMPLIFER UNDERPLAY BOARD 1
550308-2003000021 BOTTOM BOARD 2 for CC1 REVERB UNDERLAY BOARD 1
550328-1308000000 HANDLE PVC 1
550344-2003000011 CABINET for CC1 Black Vinyl 1
550406-1308000000 PLASTIC CORNER NYLON 8
550ZD-63900-01 LOUDSPEAKER for CC1 Celestion Neo Do
g
12" 16ohm 1
THE ASSEMBLY PARTS LIST AC30CC2
P/N PART NAME DESCRIPTION QUA
550078-0300000000 REVERB BL3EB3CIB 1
550084-2261100090 AUDIO CABLE φ3.8MM L=1100MM 1
550217-1327000001 LOGO PLATE KIMANSON SUPPLIED 1
550226-0250041311 RUBBER FOOT 1 φ25x12.5 4
550226-1300000621 RUBBER FOOT 2 2
550300-2004000011 FRONT PANEL for CC2&CC2X Black Vin
y
l / Grill Cloth/White Pi
p
in
g
1
550301-2004000011 BACKBOARD 1 for CC2&CC2X Black Vinyl 1
550301-2004000021 BACKBOARD 2 for CC2&CC2X Black Vinyl 1
550306-2321000001 VENT ABS LXW=143x41 3
550308-2003000011 BOTTOM BOARD 1 for CC2&CC
2
AMPLIFER UNDERPLAY BOARD 1
550308-2004000021 BOTTOM BOARD 2 for CC2&CC
2
REVERB UNDERLAY BOARD 1
550328-1308000000 HANDLE PVC 1
550344-2004000011 CABINET for CC2&CC2X Black Vinyl 1
550406-1308000000 PLASTIC CORNER NYLON 8
550ZD-53900-10 LOUDSPEAKER for CC2 Wharfedale GSH-120-8 12" 8 ohm 2
THE ASSEMBLY PARTS LIST AC30CC2X
P/N PART NAME DESCRIPTION QUA
550078-0300000000 REVERB BL3EB3CIB 1
550084-2261100090 AUDIO CABLE φ3.8MM L=1100MM 1
550217-1327000001 LOGO PLATE KIMANSON SUPPLIED 1
550226-0250041311 RUBBER FOOT 1 φ25x12.5 4
550226-1300000621 RUBBER FOOT 2 2
550300-2004000011 FRONT PANEL for CC2&CC2X Black Vin
y
l / Grill Cloth/White Pi
p
in
g
1
550301-2004000011 BACKBOARD 1 for CC2&CC2X Black Vinyl 1
550301-2004000021 BACKBOARD 2 for CC2&CC2X Black Vinyl 1
550306-2321000001 VENT ABS LXW=143x41 3
550308-2003000011 BOTTOM BOARD 1 for CC2&CC
2
AMPLIFER UNDERPLAY BOARD 1
550308-2004000021 BOTTOM BOARD 2 for CC2&CC
2
REVERB UNDERLAY BOARD 1
550328-1308000000 HANDLE PVC 1
550344-2004000011 CABINET for CC2&CC2X Black Vinyl 1
550406-1308000000 PLASTIC CORNER NYLON 8
550ZD-65000-10 LOUDSPEAKER for CC2X Celestion AlNiCo Blue 2

Vox AC30CC2 Specifications

General

Speaker	2 x 12" Celestion G12M Greenback
Channels	2 (Normal, Top Boost)
Reverb	Yes
Tremolo	Yes
Inputs	4 (2 per channel)
Effects Loop	Yes
Preamp Tubes	3 x 12AX7
Power Tubes	4 x EL84
Outputs	External Speaker, Extension Speaker
Type	Tube
Power Output	30 Watts
EQ	Bass, Treble
Footswitch	Optional
