6
The Guitarist’s Guided Panel
Tour
In this chapter we’re going to take a look at the top and rear
panels of your amp.
A. Top Panel
1
2
3
4
1. INPUT Section
This is where you plug in your guitar.
2. Power switch
When the power is on, the indicator located above
the switch will be lit.
3. AMP Section
Here’s where you adjust the settings for your ampli-
fier.
Replacing the batteries
Replace the batteries when the indicator above the
POWER switch becomes dim.
NOTE: If the battery power is low, noise may be heard.
NOTE: Depleted batteries must be removed from the DA5 im-
mediately. If you leave them in, malfunctions such as
battery leakage may occur. You should also remove the
batteries if you will not be using the DA5 for an ex-
tended time.
