10
Specications
Number of amp types: 11
Number of effects: 8
Tuner range: E1–E6 (41.2 Hz–1318.5 Hz)
Input/output jacks: INPUT, MIC IN, AUX IN, PHONES
Power amp output: Maximum approx. 3 W RMS @ 4 ohms
Speaker: 5 inch 4 ohms
Signal processing A/D conversion: 24-bit
D/A conversion: 24-bit
Power supply: Six AA/LR6 alkaline baeries
or the included AC adapter
Battery life: 12 hours
Current consumption: 150 mA
Dimensions (W x D x H): 262 x 174 x 223 mm
10.31 x 6.85 x 8.78 inches
Weigh: 3 kg/6.61 lbs. (not including baery)
Included items: AC adapter (DC 12V
), strap
* Appearance and specications of this product are subject to change
without notice.
For more information on Vox products, please visit our website at
www.voxamps.com.
• Make sure sound is coming from the amp.
You’ll need to unplug your headphones or cable from the PHONES
jack to do this, since plugging something into this jack automatically
mutes the amp’s speakers. If there’s still no sound from the amp, go to
“There’s no sound coming from the amp.” If you do hear sound, check
the headphones or cable you are hooking up to this jack.
The effects cannot be applied to the sound.
• Is the tuner function turned on?
If the tuner function is turned on, the eects will be bypassed. Press
the TAP buon to cancel the bypass.
• Is the EFFECTS or DELAY/REVERB knob set to OFF or to a lower value?
Adjust the EFFECTS and DELAY/REVERB knob.
• If the eects cannot be applied to the MIC signal, the SEND knob
might be set to a lower value.
Adjust the SEND knob.
The sound of a device connected to the AUX IN jack is not being
output.
• Make sure that the external device is connected properly.
• The volume control on the external device might be set too low.
The sound from a microphone connected to the MIC IN jack is not
being output.
• Make sure that the microphone is connected properly.
• The microphone switch could be set to o.
• The TRIM knob could be set too low.
