8. POWER Switch
Umm...this is how you turn on power to the amplifier.
Assuming it's plugged in to a working outlet, of course!! It
is plugged into a working outlet right? Good...
SETTINGS DIAGRAMS
INPUT
Jack
HEADPHONE/
LINE OUT Jack
Hard disk recorder etc.
Pathfinder 10
SPECIFICATIONS
• Dimensions (W x D x H): 380mm x 170mm x 260mm /
14.96" x 6.69" x 10.24"
• Weight: 4.8kg / 10.58 lbs
• Output Power: 10 Watts RMS into 8 Ohms
• Speaker: Vox Bulldog x 1 (6.5", 8 Ohm)
• Inputs: INPUT jack
• Outputs: HEADPHONE/LINE OUT jack
• Controls: GAIN, TREBLE, BASS, VOLUME, CLEAN/
OVERDRIVE Switch, POWER switch
* Specifications are subject to change without notice.
* Company names, product names, and names of formats etc. are
the trademarks or registered trademarks of their respective
owners.
IMPORTANT REMINDER: Your Pathfinder 10 should
only be “examined”/repaired by an
Authorized Vox
Service Centre
. Failure to do so will void your warranty.
© 2001 VOX AMPLIFICATION LTD.
Printed in Korea
