PART NAMES and FUNCTIONS
FRONT & REAR PANEL
1. Platter
Place the platter on the spindle while you are assembling your turntable. It has a drive belt wound around on the
back side.
2. Rubber mat
3. Spindle
4. Speed/Power rotary switch knob
Rotate the knob to turn on/off your turntable or select the rotation speed appropriate to the vinyl record to play.
5. Tone arm part
For details, refer to “Tone arm” paragraph.
6. Dust cover hinge holders
Attachment points for dust cover hinges.
