ICON USER’S MANUAL: SECTION 8 VIRGINIA PANEL CORPORATION
8-3 For the most current information available, visit www.vpc.com.
6/7/18
Figure F. User can use athead screws to mount the PCB as shown. This can be done when no strain relief is required.
Figure G. A strain relief plate, Part # 310 113 456 can be used with a PCB as shown. To do this put thru holes on the PCB and use a 4-40
pan head screw.
FLATHEAD SCREW
STRAIN RELIEF PLATE
THRU HOLE FOR
MOUNTING THE PCB
DISCRETE WIRING MODULE
ICON PCB MOUNTING OVERVIEW
