VPro DN - Pneumatic Actuator Specifications; TAD Double-Acting Actuator; TAO TAC Single-Acting Actuator

OSPDN20A-EN
3/8
PNEUMATIC ACTUATOR SPECIFICATIONS
TAD type
Classification Double-acting type
Actuator type TAD-040 TAD-050 TAD-063 TAD-080 TAD-100 TAD-125 TAD-160
Weight [kg] 0.9 1.3 2.1 3.4 6.1 9.8 18.2
Air consumption [ ]
(round-trip)
0.11 0.18 0.34 0.66 1.36 2.72 5.56
Operation SHUT by air to port A. OPEN by air to port B.
Air pressure 0.4 to 0.7 MPa
Piping connection Rc 1/8 Rc 1/4
Method of operation Rack-and-pinion Scotch yoke
Housing material Aluminum alloy
Ambient temperature -10 to 50 °C (Please be careful when you use in 5 °C or less, so that there no freeze.)
Manual operation Operates the upper shaft of the actuator directly.
TAO TAC type
Classification Single-acting type (Spring-return)
Actuator type TAO-040
TAC
-040
TAO-050
TAC
-050
TAO
-
063
TAC
-
063
TAO-080
TAC
-080
TAO-100
TAC
-100
TAO-125
TAC
-125
TAO
-
160
TAC
-
160
Weight [kg] 2.3 3 4.9 8.5 16.4 27.6 51.2
Air consumption [ ]
(round-trip)
0.23 0.34 0.67 1.26 2.62 4.44 8.77
Operation TAO : OPEN by air to intake port. SHUT by spring-return. (Airless SHUT)
TAC : SHUT by air to intake port.
OPEN by spring-return. (Airless OPEN)
Air pressure 0.4 to 0.7 MPa
Piping connection Rc 1/4
Method of operation Rack-and-pinion Scotch yoke
Housing material Aluminum alloy
Ambient temperature -10 to 50 °C (Please be careful when you use in 5 °C or less, so that there no freeze.)
Manual operation No manual operation. Option: MT (Manual handle unit)
