VPro DN - Valve Specifications Overview

OSPDN20A-EN
2/8
VALVES SPECIFICATIONS
Water Oil Air, Gas Steam Chemicals Sea water Slurry Negative pressure
Valve type DN
Design Wafer type
Connection JIS Flanges 5K / 10K
Fluid
Max pressure 1 MPa
Size [mm] 080 to 300
Material Body SCS13A
Disk SCS13A
Seat F-PTFE
Stem seal Packing PTFE
PRESSURE & TEMPERATURE RATING
INHERENT FLOW CHARACTERISTIC
Cv
value
(%)
Valve opening
(%)
Range ability 50:1
Max
