OSYSR225-EN
2/7
VALVES SPECIFICATIONS
Water Oil Air, Gas Steam Chemicals Sea water Slurry Negative pressure
SR SH type
Valve type SR SH
Design 2-way, Full port 2-way, Full port
Connection Threaded End Rc Threaded End Rc
Fluid
Max pressure 2 MPa 1.4 MPa 2 MPa
Size [mm] 015 to 020 025 to 040 015 to 032
Material Body SCS14A SCS14A
Ball SCS14A SCS14A
Seat PTFE F-PTFE
Stem seal Packing F-PTFE R-PTFE
O-ring - Steam resistant FKM
PRESSURE & TEMPERATURE RATING
SR SH
