VPro MAX Series - MS and MV Valve Specifications; MS;MV Valve Types; MS;MV Connection Type; MS;MV Suitable Fluids

OSYSR225-EN
3/7
VALVES SPECIFICATIONS
Water Oil Air, Gas Steam Chemicals Sea water Slurry Negative pressure
MS MV type
Valve type MS MV
Design 2-way, Full port 2-way, V-port (Reduced port) 2-way, V-port
Connection Threaded End Rc Threaded End Rc
Fluid
Max pressure 3.5 MPa 2.4 MPa 2 MPa
Size [mm] 010 to 025 032 to 050 010 to 015 015 to 050
Material Body SCS14A SCS14A
Ball SCS14A SUS316 SUS316 / SCS14A
Seat R-PTFE R-PTFE
Stem seal Packing R-PTFE R-PTFE
O-ring FKM FKM
PRESSURE & TEMPERATURE RATING
MS MV
INHERENT FLOW CHARACTERISTIC (MV)
Cv value (%)
Valve opening (%)
Range ability
MV-5UUP - 015 to 050
MV-5UUP R 010 to 015
50:1
100:1
