VPro MAX Series - MH Valve Specifications; MH Valve Design and Connection; MH Suitable Fluids; MH Maximum Pressure Ratings

OSYSR225-EN
4/7
VALVES SPECIFICATIONS
Water Oil Air, Gas Steam Chemicals Sea water Slurry Negative pressure
MH type
Valve type MH
Design 2-way, Full port
Connection Threaded End Rc
Fluid
Max pressure 14 MPa 10 MPa 7 MPa 5 MPa
Size [mm] 010 to 020 025 to 040 010 to 020 025 to 040
Material Body SCS14A
Ball SCS14A (HCr)
Seat POM R-F-PTFE
Stem seal Packing -
O-ring FKM
Note) It cannot be used POM seat for a water solution of more than 85 °C. (MH type)
PRESSURE & TEMPERATURE RATING
Seat material: POM Seat material: R-F-PTFE
MH-5UUD MH-5UUR
