VQ CESSNA 208 - Electric Motor Fire Wall Attachment; Mark and Drill Fire Wall; Attach Wooden Motor Mount

Remove the wooden motor mounting
plate and drill a 5mm hole through
the fire-wall at each of the four marks
marked .
5x80mm bolt.....4
5mm nut..........12
5mm washer...16
Attach the four 5x80mm bolts
and nuts to the fire-wall as shown.
5mm
CESSNA 208
6-Electric motor mount
Using a wooden motor mounting plate as a template,
mark the fire-wall where the four holes are to be drilled.
! Align the mark on wooden motor
mounting plate with the mark on
the fire-wall.
5mm
