4
Suspended cabinets.
Wall mounting with the double suspension rail [Fig. 1].
Step 1:
Fasten the double suspension rail (1) to the wall. In the case
of lightweight walls, screw the double suspension rail into
the stand, possibly use a load compensation plate.
Screw position Left / Right [Fig. 3].
Screw the first screw between the distress and the outer edge.
Fasten the second screw approximately 8 cm from the first
screw.
Important!No relining allowed!
The rail must lie completely against the wall!
Step 2:
Suspend the cabinet.
Step 3:
Level the cabinet and adjust the cabinet to the correct
position using a cross-head screwdriver.
Height adjustment (2).
Depth adjustment (3).
Caution! When fixing to a lightweight partition wall,
make sure that the load is distributed correctly – if in
doubt, contact the manufacturer!
Before installation, there is a need to check the suitability of
the wall construction and to check that the fasteners are able
to withstand the forces that occur. If the supplied universal
set does not match the nature of the wall, appropriate screws
and fittings must be obtained from specialist dealers to
ensure safety.
Assembly or disassembly may only be carried out by trained
specialist personnel, since there is a risk of serious accidents
if the assembly is not carried out correctly. VS Vereinigte
Spezialmöbelfabriken GmbH & Co.KG assumes no liability for
incorrect or improper installation and operation.
Caution!
Always hang cupboards above 1m (top shelf)!
Important! Make sure that the screw heads are not
slip through the holes in the suspension rail!
1 3
2
