VENTILATOR MOUNTING
CONNECTION TO POWER MAINS
Operation Instruction for the user and the qualified installer
12
DISCONNECT THE VENTILATION FROM
POWER MAINS PRIOR TO ANY ELECTRIC
INSTALLATION OPERATIONS.CONNECT
THE VENTILATOR CORRECTLY WITH A
GROUNDED TERMINAL ANY INTERNAL
CONNECTION MODIFICATIONS ARE NOT
ALLOWED AND RESULT IN WARRANTY
LOSS.
5. Install the filter, the ceramic
exchanger core, another filter and
the air flow rectifier in consecutive
order inside the telescopic air duct.
6. Install the ventilation unit on the
mounting plate. The ventilation unit
is fixed with magnets.
The ventilator is rated for connection
to single-phase AC100-240 V/ 50-60
Hz power mains.
Connect the ventilator to the socket
directly.
