♦ Torque wrench - V.A.G 1331-
♦ Tool set - T10133-
Removing:
– Remove upper part of intake manifold ⇒ page 236 .
Injectors for cylinders 1, 3 and 5
– Remove lower part of intake manifold with fuel rail
⇒ page 239 .
Injectors for cylinders 2, 4 and 6
– Removing fuel rail ⇒ page 239 .
Continuation for all cylinders
– Manually press the O-ring upwards as shown and remove it
from the injector.
– Screw slide hammer - T10133/3- to puller - T10133/15- .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
222 Rep. gr.24 - Mixture preparation - injection
