❑ When re-using the old Lambda probe, grease thread with high-temperature paste - G 052 112 A3- ; the
paste must not get into the slots of the probe body.
❑ Removing and installing ⇒ page 267
❑ 50 Nm
8 - Mounting
❑ Renew if damaged
9 - Bolts
❑ 23 Nm
10 - Mounting
❑ Renew if damaged
11 - Bolts
❑ 23 Nm
12 - Lambda probe 2 after catalytic converter - G131-
❑ The threads on the new Lambda probes are coated with a special assembly paste.
❑ When re-using the old Lambda probe, grease thread with high-temperature paste - G 052 112 A3- ; the
paste must not get into the slots of the probe body.
❑ Removing and installing ⇒ page 267
❑ 50 Nm
13 - Bolt
❑ 23 Nm
14 - Catalytic converter
❑ For exhaust bank 2
❑ Can be removed individually
❑ Protect from damage by knocks and impact.
❑ Removing and installing ⇒ page 260
15 - Holder
❑ For catalytic converter
16 - Seal
❑ Renew
17 - Nuts
❑ Renew
❑ Coat studs with high temperature paste - G 052 112 A3- .
❑ 23 Nm
18 - Lambda probe 2 - G108- (before catalytic converter)
❑ The threads on the new Lambda probes are coated with a special assembly paste.
❑ When re-using the old Lambda probe, grease thread with high-temperature paste - G 052 112 A3- ; the
paste must not get into the slots of the probe body.
❑ Removing and installing ⇒ page 267
❑ 50 Nm
19 - Exhaust manifold
❑ For exhaust bank 2
❑ Removing and installing ⇒ page 253
20 - Holder
❑ For catalytic converter
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
2. Silencers and catalytic converters 257
