SPECIFICATIONS
Dimensions: 4.8"H x 6.8"W x 4.8"D
(12.2cm x 17.3cm x 12.2cm)
Voltage: 115v/230v AC, 50/60 hertz
Current: 115v - 1.2 amps
230v - 0.6 amps
Power: 150 watts
Weight capacity: .65 lbs (294g) maximum
Speed range - fixed speed: 3200rpm
analog: 100 to 3200 rpm
230v units: 2500rpm
Orbit: 0.190" dia., .095 offset
Controls - fixed speed: None
analog: 3-way power switch
Speed knob, variable 1 to 10 dial markings
Product weight: 11lbs (5kg)
Ship weight: 11.7lbs (5.3kg)
Power switch
Speed knob
ANALOG VORTEXER MIXER
3
FIXED SPEED VORTEXER MIXER
INTRODUCTION
The Vortexer mixer is used to prepare samples for testing. It operates by mixing
tubes just prior to testing.
The 115v and 230v units are supplied with a 3-prong power cord that should be
plugged into a standard 3-prong grounded outlet. The unit is now on and in a
"standby" mode.
Your Vortexer mixer is ready for use for most one-handed applications. To install the
cup head or 3" head attachment, follow these steps:
a. Be sure the Vortexer mixer is un-plugged.
b. Place cup-head on post, aligning the "flat" inside of the head mounting hole,
with "flat" on post.
c. Press center of head down firmly until it snaps into place.
d. To remove an installed head, hold housing with one hand and pull head straight
up firmly.
