(PULSING) VORTEX MIXER
7
SPECIFICATIONS
Dimensions: 4.8"H x 6.8"W x 4.8"D
(12.2cm x 17.3cm x 12.2cm)
Voltage: 115v/230v AC, 50/60 hertz
Current: 115v - 1.2 amps
230v - 0.6 amps
Power: 150 watts
Weight capacity: .65 lbs (294g) maximum
Speed range: 500 to 3000 rpm
auto position: 1000 to 3000 rpm
pulse mode: 3000 rpm
230v units: to 2500 rpm
Orbit: 0.190" dia., .095 offset
Controls: 3-way power switch
LED display for time/speed
Up/Down keypad for set-point control
1 second to 9999 minutes
(increased in 1 second increments)
Pulsing keypad
Product weight: 11lbs (5 kg)
Ship weight: 11.7lbs (5.3kg)
Time display
Time keypad
Speed display
Speed keypad
Power switch
Pulse keypad
INTRODUCTION
The Vortexer mixer is used to prepare samples for testing. It operates by
mixing tubes just prior to testing.
The 115v and 230v units are supplied with a 3-prong power cord that
should be plugged into a standard 3-prong grounded outlet. The unit is
now on and in a "standby" mode.
Your Vortexer mixer is ready for use for most one-handed applications.
To install the cup head or 3" head attachment, follow these steps:
a. Be sure the Vortexer mixer is un-plugged.
