Vytronix R4SFL - Page 5

Product Assembly &Parts
4
2
3
1
5
6
8
7
9
10
Base Assembly:
Insert screw as shown. Tighten using
a flat-head screwdriver. If screw turns
freely without "gripping" the insert
threads, apply additional pressure
when turning.
Floor Setting Indicator Light:
Ideal for ceramic, stone, tile and
other durable floors.
Perfect for sealed hardwood,
laminate, bamboo and other
delicate floors
11
12
13
