torque shall be big enough to fix it steadily. For safety, it is better to follow the clamp manufacturer’s
recommendations.
Clamp types:-
Mid clamps: - They hold each neighbouring panel on the purlin.
End clamps: They hold the panel at fringes at their position.
INSTALLATION DIAGRAM:-
Fringe module installation
Middle module installation
