10
Note: - The clamp position must be in range L/8 ≤ e ≤ L/4, a≥ 6cm
GROUNDING
All Module frames and mounting racks must be properly grounded in accordance with respective
national electrical code. The earth grounding connection shall be done by a qualified electrician. The
longer sides of the Module frames are equipped with predrilled Earthing holes in their centre.
Fixing with Nut-Bolts
Fixing with Clamping system
