CAS-GPS IVU BASIC SYSTEMS INSTALLATION MANUAL DOCU0085 Revision Q
Interconnections – Light Vehicle
VEHICLE
POWER VIA
FUSE
6 WAY DEUTSCH
CONNECTOR
INTERFACE
LIGHT VEHICLE
RF UNIT
(PROD0295)
CASGPS IN-VEHICLE
UNIT (IVU)
CASGPS DISPLAY
PROD0850-xM
CASGPS IVU TO
DISPLAY CABLE
REVERSE
SIGNALS AND
IGNITION SIGNAL
PROD0296
LV RF INPUT
CABLE
