CAS-GPS IVU BASIC SYSTEMS INSTALLATION MANUAL DOCU0085 Revision Q
Installation
Installation should be in accordance with:
• Vehicle manufacturers instructions.
• National/local & site regulations relevant to the location of install.
• The installation procedures defined by Digital Mining Technology and only performed by authorised and qualified installers.
This radio transmitter IC: 8903A-PROD08422 & IC: 8903A-PROD08472 has been approved by Industry Canada to operate with the antenna types listed below with the
maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use
with this device.
Cet émetteur radio IC : 8903A - PROD08422 & IC : 8903A - PROD08472 a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous
avec le gain maximal admissible indiqué . types d'antennes non inclus dans cette liste , ayant un gain supérieur au gain maximum indiqué pour ce type , sont strictement
interdits pour une utilisation avec cet appareil.
GE Part#
Relevant Product
(x = any variant)
CAS
-GPS Port
Nominal
Impedance
Max. Gain
Operating Frequency
PROD0852 PROD084x-2 V2V 50 Ω +3dBi 902-928MHz
PROD0874 PROD084x-1 V2V 50 Ω +3dBi 821-896MHz
MISC0467 or
PROD1222
PROD084x-x GPS (Receive Only) 50 Ω +17 to +50 dB GPS: L1(1559 to 1610MHz), L2(1164 to 1215MHz)
Galileo: E1 (1559 to 1610MHz), E5(1164 to 1215MHz)
BDS: B1L (1559 to 1610MHz)
GLONASS: G1 (1559 to 1610MHz),G2 (1215 to 1300MHz)
PROD0854 PROD0847-x GSM / 3G 50 Ω 0dBi
+1.7dBi
+2.9dBi
700, 800, 850, 900, 1800, 1900, 2100, 2600 MHz
PROD0833 PROD084x-x Wi - Fi 50 Ω +3.0dBi 2400-2484MHz
